Synthetic Fiber Extrusion Production Line Professional PVC Hair Fiber Production Solution
I. Product Description
Synthetic hair fiber is made from PVC materials and additives through a filament extruder. It is one of the world's most popular and best-selling flame-retardant synthetic hair fibers and can be processed into various hair products such as Yaki hair fiber, giant braids, straight hair extensions, crotch extensions, weft hair extensions, and gradient hair.
II. Equipment Advantages (Core Selling Points)
Turnkey Service: Provides equipment + specialized formula + process technology + after-sales support as a one-stop solution
Professional Formula: Optimized PVC formula ensures fiber flame retardancy, softness, and durability
Mature Process: 10+ years of professional experience, precise control of fiber diameter, softness, and strength
Customization Service: Supports OEM customization, can customize brand, appearance, and packaging according to customer needs
Permanent Technical Support: Remote video guidance, process optimization, problem diagnosis
III. Technical Parameter Table
| Item | Parameter |
| Applicable Raw Material | PVC and Special Additives |
| Extruder Type | Single Screw (Precision Type) |
| Screw Diameter | Φ45~Φ90 mm |
| Die Head Type | Special Hair Fiber Die Head |
| Fiber Diameter Range | 0.05~0.20 mm |
| Number of Die Holes | 12~100 Holes |
| Line Speed | 5~30 m/min |
| Control System | PLC + Precise Temperature Control + Drawing Control |
| Cooling Method | Water Trough Cooling |
| Winding Method | Precision Winding, suitable for subsequent processing |
IV. Formula Table Example (PVC-based Synthetic Hair Fiber)
| Component | Proportion (%) | Function |
| PVC Resin | 70~85% | Main material, determines basic fiber properties |
| Plasticizer | 10~20% | Enhances softness and toughness |
| Stabilizer | 2~5% | Improves thermal stability, prevents decomposition |
| Flame Retardant | 3~8% | Enhances flame retardancy, improves safety |
| Color Masterbatch | 1~3% | Provides various hair colors |
| Lubricant | 0.5~1.5% | Improves processing fluidity |
V. Equipment List (Typical Configuration)
| No. | Equipment/System | Function |
| 1 | Raw Material Mixing System | Ensures uniform mixing of raw materials |
| 2 | Single Screw Extruder | Precision melting and plasticizing |
| 3 | Special Hair Fiber Die Head | Multi-hole fiber extrusion |
| 4 | Cooling Water Trough | Uniform cooling and setting |
| 5 | Drawing Device | Controls fiber strength and softness |
| 6 | Winding Machine | Precision winding, convenient for subsequent processing |
| 7 | Electrical Control System | Precise temperature and speed control |
VI. Process Flow Chart
[Raw Material Mixing] → [Extruder Melting] → [Special Die Head Extrusion] → [Cooling Water Trough Setting] [Drawing Device] → [Winding Machine] → [Post-processing/Processing into Hair Products]
VII. Application Fields
Wig Manufacturing (Full wigs, hair extensions, hairpieces, etc.)
Hair Accessories (Braids, hair wefts, hair caps, etc.)
Cosmetics, Hair Product Brands
Personalized Customization, High-end Realistic Hair Products
VIII. Export Markets (Europe & America, Africa, Middle East, etc.)
IX. About Us
Headquarters: Shandong, China, Founded: 2014
Company Scale: 3 branch factories, 2 major industrial parks, 100+ employees
Market Distribution:Domestic: 35%,North America: 9%,South Asia/South America/Eastern Europe/Middle East: 7%~5% each
Service Principle:Quality First, Turnkey Project,Full-process Technical Support,Supports OEM Customization,Permanent Online Video Technical Support
