PTT Synthetic Hair Fiber Production Line


Using PTT (polytrimethylene terephthalate) as the core raw material, through proprietary long-fiber extrusion technology, produces high-elasticity, high-gloss, heat-resistant, easy-to-manage synthetic hair strands specifically designed for wigs, hair extensions, wefts, etc. The production line includes raw material drying system, PTT-specific single/twin-screw extruder, precision metering pump, multi-hole spinneret, slow cooling device, drawing and setting system, winding collection device, and other core modules. Supports flexible customization for filament diameters of 0.08-0.3mm and daily capacity of 50-200kg. Can be processed into various high-end hair products like Yaki hair, straight extensions, curly wigs, gradient wefts, and extension accessories.

Contact Us

Product Details


I. Product Overview

PTT Synthetic Hair Fiber Material (Ht Matt Fiber) is one of the world's most popular and best-selling high-temperature synthetic hair fibers, featuring excellent heat resistance, elastic recovery, and soft touch. It can be processed into various hair products such as Yaki hair fiber, giant braids, straight hair extensions, crochet hair, weft extensions, and gradient hair, widely used in wig making, braiding, lace wigs, crochet styles, and other fields. PTT synthetic hair fiber is a professional hair material with high temperature tolerance and superior elasticity, suitable for manufacturing various high-end hair products.

II. Product Advantages

High Temperature Tolerance: Withstands styling temperatures up to 180°C, suitable for use with various heat styling tools.

Excellent Elasticity: Superior elastic recovery performance, quickly returns to original shape after stretching, resistant to deformation.

Good Dyeability: Easy to dye, with full and lasting color, achieving rich color effects.

Lightweight and Soft: Light texture, soft and natural feel, comfortable to wear without burden.

High Durability: Resistant to wear and tear, long service life, maintains long-lasting beauty.

Eco-friendly and Safe: Complies with environmental standards, free of harmful substances, safe for humans and the environment.

III. Technical Parameters

ItemParameter
Material TypePTT (Polytrimethylene Terephthalate)
Fiber Diameter0.03~0.15 mm (Customizable)
Heat Resistance TemperatureMax 180°C
Breaking Strength≥3.5 cN/dtex
Elongation at Break30%~50%
Elastic Recovery Rate≥90% (5% elongation)
Flame RetardancySelf-extinguishing
Light Fastness≥4 Grade (Xenon lamp exposure)
Chemical ResistanceResistant to weak acids, weak alkalis, and most solvents

IV. Formula Example (PTT-based Hair Fiber)

ComponentProportion (%)Function
PTT Resin85~92%Main material, provides excellent elasticity and heat resistance
Heat-resistant Modifier3~6%Further enhances high-temperature performance
Antistatic Agent1~2%Reduces static electricity, prevents fiber adhesion
UV Absorber0.5~1.5%Improves light fastness, prevents fading
Color Masterbatch2~4%Provides various hair color options
Lubricant0.5~1%Improves processing fluidity

V. Production Equipment List

No.Equipment/SystemFunction
1Raw Material Drying SystemEnsures thorough drying of PTT raw material, prevents hydrolysis
2Precision Single Screw ExtruderMelts and plasticizes PTT raw material
3Specialized Hair Fiber Die HeadMulti-hole fiber extrusion, controls fiber diameter
4Cooling SystemRapid cooling and setting, ensures stable fiber structure
5Drawing DeviceControls fiber orientation and mechanical properties
6Heat Setting DeviceEliminates internal stress, improves dimensional stability
7Winding MachinePrecision winding, facilitates subsequent processing

VI. Production Process Flow

[PTT Raw Material Drying] → [Extruder Melting] → [Specialized Die Head Extrusion] → [Cooling and Setting]→ [Multi-stage Drawing] → [Heat Setting] → [Winding] → [Post-processing/Processing into Hair Products]

Process Description: PTT hair fiber production requires strict control of drying conditions to prevent raw material hydrolysis. Extrusion temperature is typically between 245-260°C. Through multi-stage drawing and heat setting processes, hair fibers with excellent elasticity and heat resistance can be obtained.

VII. Application Fields

Wig Extensions, Braided Hair Products, Lace Wigs, Crochet Styles, Yaki Hair Fiber, Straight Hair Extensions, Gradient Hair, Weft Extensions

VIII. About Us

Headquarters: Qingdao, Shandong, China, Founded: 2014, Company Scale: 3 branch factories, 2 major industrial parks, 100+ employees, Professional Experience: 10+ years

Market Distribution: Domestic: 35%, North America: 9%, South Asia/South America/Eastern Europe/Middle East: 7%~5% each

IX. Service Philosophy

Quality First, Turnkey Projects, Full-process Technical Support, Supports OEM Customization, Permanent Online Video Technical Support.

R&D and Technical Strength

R&D and Technical Strength

APEX has a professional mechanical technology R&D team covering mechanical design, automation control, materials science, etc., capable of product design, R&D, and improvement. Innovates in manufacturing processes, automation, and intelligent control.
